Hydraulic Flow Dividers

Hydraulic flow dividers distribute the flow coming from a single pump, equally or in pre-defined ratios, amongst 2 or more actuators. Raptor Supplies offers a wide range of hydraulic flow dividers from Chief and Haldex. These rotary gear type flow dividers are used to synchronise 2 parallel motions hydraulically rather than mechanically. They feature permanently moulded cast iron construction capable of withstanding operating pressure up to 3000 PSI and an integral differential relief valve for reducing built-up pressure inside. The 11 tooth hardened steel gears can rotate at a maximum speed of 4500 RPM, delivering an outer liquid pressure of 4500 PSI. Choose from a wide range of hydraulic flow dividers, available in 2.4 to 5, 2.5 to 5, 5 to 10 and 10 to 20 GPM flow ratings.

Haldex Barnes 1100042 Flow Dividers:

• It features moulded cast iron construction for structural rigidity and easy cleaning.
• This flow divider has an integral differential relief valve to limit the differential pressure between two unmixable fluids.
• It comes with 11-tooth-hardened steel gears for ease of operation.
• This flow divider offers flow rates ranging from 10 to 20 GPM.
• Models such as, 1020075 and 1020076 flow dividers offer flow rates of 2.4 to 5 GPM and 5 to 10 GPM respectively.

Chief FM-4R4.2S Hydraulic Flow Divider:

• This flow divider has aluminium construction to resist corrosion on exposed surfaces.
• It features a flow divider valve to maintain equal flow to two or more actuators.
• This flow divider offers flow rates ranging from 2.5 to 5 GPM.
