| Item | Eccentric Reducer Coupling |
|---|---|
| Application | Air, Natural Gas, Non-Potable Water, Oil, Steam |
| Basic Fitting Shape | Coupling |
| Body Material | Cast Iron |
| Class | Class 125 |
| Color | Black |
| Connection Type | Flanged |
| Fitting Side A Nominal Pipe Size | 3" |
| Fitting Side A Type | Flanged |
| Fitting Side B Nominal Pipe Size | 2 1/2" |
| Fitting Side B Type | Flanged |
| For Pipe Schedule | 40 |
|---|---|
| Includes Pre-applied Thread Sealant | No |
| Includes Seal | No |
| Max. Pressure | 175 psi @ -20° To 150°F |
| Maximum Operating Pressure | 175 psi @ 150°F |
| Pipe Fitting Material | Cast Iron |
| Pipe Size | 3" x 2 1/2" |
| Saturated Steam Pressure | 125 psi |
| Specific Fitting Shape | Eccentric Reducer Coupling |
| Standards | Asme B1.20.1, Asme B16.4, Astm A126, Astm A153, Fm Approved, Ul Listed |
| Temp. Range | -20°F to +150°F |
| Height (cm) | 15.54 |
|---|---|
| Length (cm) | 15.24 |
| Width (cm) | 27.56 |
| HS Code | 7307110030 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 9.9 |
