| Item | Hoist Ring |
|---|---|
| Application | Lifting |
| Dimension B | 7/16" |
| Dimension C | 21/64" |
| Dimension E | 63/64" |
| Eye Inside Diameter | 63/64" |
| Eye Thickness | 0.344" |
| Industry Standards | Dguv-R 109-017:2020-12, Din En 1677-1:2009-03, Din En Iso 12100:2011-03 |
| Material | Steel |
| Mounting Style | Bolt On |
|---|---|
| Nominal Size | M8 |
| Pitch | 35 mm |
| Pivot Angle | 0° |
| Swivel Angle | 360° |
| Thread Length | 9/16" |
| Thread Size | M8 x 1.25 |
| Working Load Limit | 660 lbs. |
| Height (cm) | 7.49 |
|---|---|
| Length (cm) | 11.51 |
| Width (cm) | 11.4 |
| HS Code | 8431310060 |
|---|---|
| Country Of Origin | DE |
| Weight (kg) | 0.108 |
