| Item | Electronic Digital Caliper |
|---|---|
| Absolute Positioning | Yes |
| Accuracy | -0.002" to +0.002" |
| Battery Included | Yes |
| Battery Size | CR2032 |
| Calibration Certificate | No |
| Caliper Grouping | Digital Caliper |
| Caliper Material | Carbon Fiber |
| Case | Wooden |
| Case Material | Wooden |
| Case Type | Wood Case |
| Compatible Spc Cable | Mfr. No. 1500-3A-18N Datasure End Node, Mfr. No. 798SCKB Smartcable USB-Keyboard Output, Mfr. No. 798SCU Smartcable USB-RS232 Output |
| Coolant Resistant | Yes |
| Data Output Connection Type | RS232, USB |
| Data Output Type | Cable |
| Display Type | LCD |
| Functions | Hold, In./mm Conversion, Two Preset Modes |
| Included | Pt06137 Pair Of Disc Contacts 20 mm For 5002Bz Series, Pt06138 Pair Of Step Contacts 5-10-20 mm For 5002Bz Series, Pt06139 Pair Of Cone Contacts 30 mm For 5002Bz Series |
| Included Case | Yes |
| Ip Rating | Not Rated |
|---|---|
| Jaw Depth | 4 29/32" |
| Jaw Material | Steel |
| Jaw Shape | Disc Contacts |
| Long Form Calibration Certificate | No |
| Material | Carbon Fiber |
| Max. Measurement | 24" , 600 mm |
| Measurements | Outside |
| Measures Depth | No |
| Measures Inside Dimension | No |
| Min. Measurement | 0 mm |
| Min. Measurement-inch | 0" |
| Product Type | Conical Point Digital Caliper |
| Range | 0" to 24", 0 mm to 600 mm |
| Resolution | 0.0005" |
| Spc Output | Yes |
| Water Resistance | Yes |
| With Locking Nut | Yes |
| Height (cm) | 7.62 |
|---|---|
| Length (cm) | 76.2 |
| Width (cm) | 30.48 |
| HS Code | 9017304000 |
|---|---|
| Country Of Origin | IT |
| Weight (kg) | 1.9125 |
| Style | Model | Range | Resolution | Accuracy | Jaw Depth | Case | Material | Jaw Actuation Type | Spc Output | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | EC799A-12/300 | 0" to 12" | 0.0005" | -0.0015" to +0.0015" | 2 1/2" | Plastic | Stainless Steel | Thumb Wheel | No | SGD 1,346.43 | |
| B | EC799A-6/150 | 0" to 6", 0 mm to 150 mm | 0.0005" | -0.001" to +0.001" | 1 1/2" | Plastic | Stainless Steel | Thumb Wheel | No | SGD 537.18 | |
| C | 799AZ-24/600 | 0 mm to 600 mm | 0.0005" | -0.002" to +0.002" | 4" | Plastic | - | Thumb Wheel | No | SGD 2,610.15 | |
| D | 799AZ-40/1000 | 0 mm to 1000 mm | 0.0005" | -0.003" to +0.003" | 6" | Plastic | - | Thumb Wheel | No | SGD 4,988.33 | |
| E | B5000BZ-24/600 | 0" to 24", 0 mm to 600 mm | 0.0005" | -0.002" to +0.002" | 4 59/64" | Wooden | Carbon Fiber | Fine Adjust Carriage | Yes | SGD 5,070.77 | |
| F | B5000BZ-40/1000 | 0" to 40", 0 mm to 1000 mm | 0.0005" | -0.003" to +0.003" | 4 59/64" | Wooden | Carbon Fiber | Fine Adjust Carriage | Yes | SGD 5,551.28 | |
| G | 5006BZ-14/350 | 0" to 14" | 0.0005" | -0.002" to +0.002" | 3.94" | Wooden | Stainless Steel | - | Yes | SGD 4,737.71 |
