| Item | Collet |
|---|---|
| Bore Shape | Round |
| Clamping Hole Length | 18 mm |
| Collapse Range | 2 mm to 2.5 mm |
| Collet Series | ER11 |
| Collet Size | 2.5 mm |
| Collet Type | Standard |
| Coolant Fed | Coolant Through |
| Coolant Through | Yes |
| Face Shape | Round |
| Max Pressure | 2000 psi |
|---|---|
| Max. Body Dia. | 2.5 mm |
| Number Of Slots | 8 |
| Outside Diameter - Maximum | 11.5 mm |
| Overall Length | 18 mm |
| System Of Measurement | Metric |
| T.i.r. Tolerance | 0.0002" |
| Taper Angle | 8° |
| Tir Max. | 0.0002" |
| Torque - Maximum | 17 lbs.-ft. |
| Height (cm) | 2.54 |
|---|---|
| Length (cm) | 2.54 |
| Width (cm) | 2.54 |
|---|---|
| Weight (kg) | 0.0135 |
| Style | Model | Face Shape | Max. Body Dia. | Collet Type | Collet Series | Material | Finish | Tir Max. | Clamping Hole Length | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 05546 | - | - | - | ER25 | High Carbon Steel | Precision Ground | - | - | SGD 125.73 | |
| B | 04542-1/8 | - | - | Sealed Coolant | ER11 | High Carbon Steel | Precision Ground | - | - | SGD 127.71 | |
| A | 05348 | - | - | - | ER16 | High Carbon Steel | Precision Ground | - | - | SGD 109.68 | |
| A | 05346 | - | - | - | ER16 | High Carbon Steel | Precision Ground | - | - | SGD 109.68 | |
| B | 04542-1/4 | - | - | Sealed Coolant | ER11 | High Carbon Steel | Precision Ground | - | - | SGD 128.41 | |
| B | 04542-3/16 | - | - | Sealed Coolant | ER11 | High Carbon Steel | Precision Ground | - | - | SGD 128.41 | |
| C | 13/0-4036 | Round | 0.141" | ANSI Clutch Drive Tap | Ansi 0 | - | - | - | - | SGD 188.42 |
