| Item | Electrical Tape |
|---|---|
| Adhesion To Steel | 30 oz./in. |
| Adhesive | Acrylic |
| Adhesive Material | Acrylic |
| Adhesive Properties | Pressure Sensitive Adhesive |
| Breakdown Voltage | 5000V |
| Breaking Strength | 25 lbs./in. |
| Color | Yellow |
| Color Family | Yellow |
| Core Dia. | 3" |
| Duct Tape Adhesive | Acrylic |
| Elongation | 100% |
| Imperial Tape Length | 216 ft. |
| Imperial Tape Width | 1/2" |
| Insulation Resistance | 1 x 10^6 M Ohms |
| Length | 72 yd. |
| Liner Included | No Liner |
| Material | Polyester |
| Max. Voltage | 5500V |
| Maximum Tape Performance Temperature | 265°F |
| Metric Tape Length | 65.84m |
| Metric Tape Width | 12.7 mm |
| Min. Performance Temp. | Not Rated |
| Performance Temp. | Up To 266°F |
|---|---|
| Printed Message | Unprinted |
| Product Form | Continuous Roll |
| Series | 1318-1 Series |
| Shape | Continuous Roll |
| Specifications Met | ASTM, UL |
| Tape Adhesive Format | Single-Sided |
| Tape Adhesive Material | Acrylic |
| Tape Backing Construction | Film |
| Tape Backing Material | Polyester |
| Tape Color | Yellow |
| Tape Properties | Flagging Resistant, Solvent Resistant |
| Tape Resistance Properties | Flagging-Resistant, Solvent-Resistant |
| Tape Sub-type | Abrasion-Resistant |
| Tape Tensile Strength | 25 lbs./in. |
| Tape Thickness | 1 mil. |
| Tape Type | Film |
| Temp. Range | Up To 266°F |
| Thickness | 1 mil. |
| Voltage Rating | Not Rated |
| Width | 1/2" |
| Standards | ASTM D1000, UL LISTED |
| Height (cm) | 1.52 |
|---|---|
| Length (cm) | 11.43 |
| Width (cm) | 11.43 |
| HS Code | 3919102055 |
|---|---|
| Country Of Origin | TW |
| Weight (kg) | 0.072 |
| Style | Model | Color | Tape Thickness | Max. Voltage | Tape Color | Breakdown Voltage | Tape Sub-type | Tape Backing Material | Tape Adhesive Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 3M 1318-1 0.25 x 72 yds Yellow | Yellow | 1 mil. | 5500V | Yellow | 5000V | Abrasion-Resistant | Polyester | Acrylic | SGD 35.22 | |
| A | 3M 1318-1 0.75 x 72 yds Yellow | Yellow | 1 mil. | 5500V | Yellow | 5000V | Abrasion-Resistant | Polyester | Acrylic | SGD 97.50 | |
| A | 3M 1318-1 1 x 72 yds Yellow | Yellow | 1 mil. | 5500V | Yellow | 5000V | Abrasion-Resistant | Polyester | Acrylic | SGD 136.31 | |
| A | 3M 1318-1 2 x 72 yds Yellow | Yellow | 1 mil. | 5500V | Yellow | 5000V | Abrasion-Resistant | Polyester | Acrylic | SGD 277.61 | |
| B | 3M 1318-2 0.25 x 72 yds Yellow | Yellow | 2 mil. | 7000V | Yellow | 7000V | Abrasion-Resistant | Polyester | Acrylic | SGD 48.83 | |
| B | 3M 1318-2 0.5 x 72 yds Yellow | Yellow | 2 mil. | 7000V | Yellow | 7000V | Abrasion-Resistant | Polyester | Acrylic | SGD 115.16 | |
| B | 3M 1318-2 0.75 x 72 yds Yellow | Yellow | 2 mil. | 7000V | Yellow | 7000V | Abrasion-Resistant | Polyester | Acrylic | SGD 161.01 |
