| Item | Machinists Level |
|---|---|
| Accuracy | 80-90 Seconds Or 0.005" Per Foot |
| Base Length | 12" |
| Case | None |
| Construction | Cast Iron |
| Cross Test Vial | Yes |
| Description | With Single Plumb Vial And Cross Test Vial |
| Features | Cross Test Vial |
| Frame Material | Cast Iron |
| Graduations | 0.42 mm/m |
| Height | 3" |
| Includes | No Certification Included |
| Length | 12" |
| Level Orientation | Horizontal |
| Material | Cast Iron |
| Number Of Cross Test Vials | 1 |
| Number Of Level Vials | 2 |
|---|---|
| Number Of Plumb Vials | 1 |
| Number Of V-grooves | 1 |
| Overall Height | 2 3/4" |
| Overall Length | 12" |
| Overall Width | 1 7/16" |
| Plumb Vial | Single |
| Precision Vial Properties | Graduated, Grounded |
| Product Type | Machinist Level |
| Sensitivity | 0.005 in./ft. |
| Shape | Straight |
| Slc Certification | Optional Add-On |
| Total Number Of Vials | 3 |
| Type | Precision |
| Vial Material | Glass |
| Vial Shape | Barrel |
| Height (cm) | 4.32 |
|---|---|
| Length (cm) | 32.77 |
| Width (cm) | 7.87 |
| HS Code | 9015308000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 1.485 |
